10m Serial Port Laser Distance Sensor For Industrial Robot
Product number：U85-10m(k191210)
Measuring distance：0.03-10m
Accuracy：+/-1mm
Frequency：3Hz
Size：41*17*7mm
The U series laser range sensor is a high accuracy distance sensor of +-1mm. With diffuse reflection and phase principle, the serial distance sensor has widely used in many industrial applications, like navigation, construction industry, intelligent transportation, warehousing and logistics, etc.
10m Serial Port Laser Distance Sensor For Industrial Robot
The U series laser range sensor is a high accuracy distance sensor of +-1mm. With diffuse reflection and phase principle, the serial distance sensor has widely used in many industrial applications, like navigation, construction industry, intelligent transportation, warehousing and logistics, etc.
Our 10m short-range laser ranging module has an effective distance of 10m, which can meet general indoor measurement and short-range outdoor measurement. The communication method is asynchronous serial communication. There are several configurations of electronic distance sensors, some of which detect or measure distances are represented by ttl, some are represented by usb or rs232. Laser level measurement laser sensors, also called laser photoelectric sensors, are usually used to detect the distance of an object, but this is not the focus of this discussion. The 20m long-distance measurement sensor is actually on a laser distance sensor. As the name implies, it can measure distance. Width measurement sensors are available for PLCs.
JRT has been producing laser ranging sensors since 2004, is a manufacturer in Chengdu, our mainly popular products are high-precision laser range sensors, long-distance laser measure sensors, high-frequency laser LiDAR sensors, high-protection laser rang distance sensors and so on.
Our laser measurement sensors are exported to more than 160 countries and regions around the world, and there are many types of single products with sales of more than 10 million. Welcome to contact us to choose the suitable model for your laser ranging solution.
Technical specifications For Laser Range Finder Module:
Range: 0.03-10 meters
Invisible measuring: 635m
Measuring accuracy: +-1 mm
Frequency：3Hz
Weight：about 4g
Interface options: Serial/usb/rs232/rs485/bluetooth
Size: 41*17*7mm
Working temperature: 0 ~ 40 degree
Storage temperature: -25 ~ 60 degree
Note:
Note: The working voltage of the module is DC2.5 ~ 3.3V. Although the voltage of DC3.3V ~ 5.5V will not burn the module immediately, it will still cause damage to the module, so please do not use the voltage above DC3.3V!
Front & Back
Mechanical Dimensions
Application
1. Measure unsuitable objects, measure height and distance.
2. In the field of automation, it solves the problem of long-distance measurement and inspection in an automatic detection and control manner. It can be used to measure the height of the bag, the distance and height of objects on the conveyor belt, the diameter of the log, etc.
3. Vehicle speed, safety distance measurement and flow statistics.
4. Height limit measurement, building limit measurement; ship safety docking position monitoring, container positioning.
Chengdu JRT Technology Co., Ltd.
