Range Finders 1200m
Laser Distance Sensor model: TC22(k230216-3)
Measuring Range: 3m -1200m
Accuracy: ±0.5m
Frequency: Up to 1Hz
Volume：43*φ25mm
Weight：15g
Transducers
Are you looking for a long range vision binoculars? Does your project need laser measuring functions with serial transportation? Then you should go for our newly developed TC22 laser range sensor. It's a precise measuring instrument featured with cylinder design which is the best choice for laser binoculars and monoculars. We can do OEM/ODM service as well.
Product Parameters:
Range: 3 - 1200m
Measuring accuracy: ±0.5m
Resolution: 0.1m
Working Voltage: 2.5~3.5V
Laser Type: 905nm
Size: 43*φ22mm (43mm long, 22mm diameter)
Weight：15g
Current: 100mA
Power: 330mW@3.3V
Baud rate: 115200bps (default)
Working temperature: 0-50 ℃(Lower temperature can be customized)
Storage temperature: -20 ~ 50 degree
Products SHOW
