Short Distance Small Laser Ranging Sensor Manufacturer

Brand：JRT
Product Number：1211U81
Measuring distance：0.03-20m
Accuracy：+/-1mm

JRT laser distance module

The effective distance of our short-range serial laser ranging module is 20m, which can meet the general indoor measurement and short-range outdoor measurement. There are various data output modes: RXTX, USB, RS232, RS485, Bluetooth are available for your choice. Our company has more than ten years of experience in the field of laser ranging modules. If you need to customize related products, you can contact us.

application area

Measuring package

Stacker crane

Elevator

Industrial laser distance sensor feature:

1. The measurement accuracy is millimeter level, and the error of the measurement result under standard conditions is about 1mm, which is data you can trust.

2. It is easy to measure using the laser ranging principle (non-contact ranging), such as artificial ceiling or other equipment.

3. Small size, weighs only about 10g, easy to operate, and does not require someone to pull the other end like a tape measure.

4. No ladder required: Safely measure hard-to-reach areas.

U81-1126 Size

U81-1126

Specifications Of Laser Distance Meter Sensor:

Brand Name	JRT
Production Number	U81
Certification	FDA/ISO9001
Place of Origin	China
Precision	±1 mm
Measuring Unit	mm
Measuring Distance (without Reflection)	0.03-20m
Measuring Time	0.125~4 seconds
Laser Class	Class II
Laser Type	620-690nm, 1mW
Volume	45177mm (±1 mm)
Weight	About 4g
Power supply voltage	DC2.0~3.3V
Electrical Level	TTL/CMOS
Frequency	3HZ / 8Hz
Operating Temperature	0-40 ℃ (32-104 ℉ )
Storage Temperature	-25~60 ℃ (-13~140 ℉)

Application

It provides application flexibility for a variety of different situations, which can include the following:

① Target positioning.

② Measure the material level of the package.

③ Measure the distance and height of objects on the conveyor.

④ Measure the diameter of logs.

⑤ Protect the overhead crane from collision.

⑥ No error checking occasions.

Chengdu JRT Meter Technology Co., Ltd,

Certification-1127

We accept T/T,PayPal,Western Union,Alibaba etc.

Shippment will be arrangeed within 3-5 business days of payment received.

All major credit cards are accepted through secure payment processor PayPal.

TOTAL AMOUNT DUE includes the products price plus S&H (Shipping and Handling).

S&H will be determined based upon the ship to address, thanks for choosing JRT.

Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor, Laser Distance Meter Sensor, Long Rangefinder Module, TOF High Frequency LiDAR Sensor.

For more info, please feel free to contact us

Hot Tags: short distance small laser ranging sensor manufacturer, China, manufacturers, suppliers, factory, wholesale, customized, cheap, quotation, OEM, low price
