700m Infrared Ranging Sensor
Laser Distance Sensor model: TC22-700m(k221125)
Measuring Range: 3m -700m
Accuracy: ±1m
Frequency: Up to 1Hz
Volume：43*φ22mm
Weight：15g
700m Night Vision Pulse Ranging Sensor UART
This pulse ranging sensor can measure up to 700 meters with stable and strong ranging ability, achieving high precision of ±1 meter accuracy, 0.1m resolution. The single measurement time is less than 1s with low-power consumption. It has light weight about 15g and small size of 43mm length and 22mm diameter. This eye safe laser sensor is feasible for outdoor gun sight and night vision long range measurement, working under high and low temperature resistance from -20~+50℃. It is UART TTL output using flat cable, easy for installation.
Product Parameters:
Range: 3 - 700m
Measuring accuracy: ±0.5m
Resolution: 0.1m
Working Voltage: 2.5~3.5V
Interface options: Serial/TTL/rs232/rs485/Bluetooth
Laser Type: 905nm
Size: 43*φ22mm (43mm long, 22mm diameter)
Weight：15g
Current: 100mA
Power: 330mW@3.3V
Baud rate: 115200bps (default)
Working temperature: 0-50 ℃(Lower temperature can be customized)
Storage temperature: -20 ~ 50 degree
700m Ranging Module Mechanical Size
Pulse Ranging Sensor Working Principle
How to pack your sample Ranging Sensor?
Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor, Laser Distance Meter Sensor, Long Rangefinder Module, TOF High Frequency LiDAR Sensor.
For more info, please feel free to contact us
