50m Distance Measurement Laser Sensor
Laser Sensor Model: M703A-50m(k20914)
Measuring Range: 0.03-50m
Frequency: 8Hz
Size：45*25*13mm
Weight：About 9g
Applications: material silo height measurement, tunnel detection, automatic robot ranging etc.
50m Industrial Laser Distance Sensor Warehouse Serial Module
Description:
The M703A 50m industrial laser distance sensor is the latest serial module of Chengdu JRT, with a distance of up to 50m. Industrial laser distance sensors have been widely used in warehouse logistics, material silo height measurement, tunnel detection, automatic robot ranging and other fields. JRT has been developing industrial laser distance sensor technology since 2004. What are the new features? The measurement response time is much faster, and up to 8 values can be returned in one second.
Data output method:
The common output interface of industrial ranging sensor is the ranging module with serial port. You can directly purchase the product. We can also solder USB, RS232, RS485, etc., so that you have more choices.
The 50m Distance Measurement Sensor is good for industrial area:
Specification:
Brand Name | JRT |
Product Name | Laser Distance Meter Sensors |
Model Number | M703A-50m(k20914） |
Certificate | FDA/ISO9001 |
Place of Origin | Chengdu |
Accuracy | ±1 mm (0.04 inch) |
Measuring Unit | mm |
Measuring Range (without Reflection) | 0.03-50m |
Measuring Time | 0.125~4 seconds |
Laser Class | Class II |
Laser Type | 635nm,<1mW |
Size | 45*25*13mm (±1 mm) |
Weight | About 9g |
Voltage | DC2.0~3.3V |
Electrical Level | TTL/CMOS |
Frequency | 3Hz~8Hz |
Operating Temperature | 0-40 ℃ |
Storage Temperature | -25~60 ℃ |
Packaging | Neutral packing |
Tips:
1. Do not operate with electricity to avoid any mistakes such as burning circuit or electric shock.
2.Under strong light or bad diffusere flectance of target, please use a reflect.
3. It is best to install it away from magnetic fields or conductors to avoid false errors.
Product show:
The distance sensor is very small size only 45*25*12mm:
50m Distance Measurement Laser Sensor diagram
Our service:
1. OEM and ODM are welcome.
2. One year warranty period
3. Sample delivery time: 1-5 days
4. Lifetime technical support.
FAQ：
(1) Q. What is your minimum order quantity?
A: You only need to purchase one and we can ship it to you.
(2) Can OEM/ODM?
A: We can provide OEM ODM services. We know that brand owners care about the quality of our products. Therefore, the choice of materials and the design of our products will be strictly in accordance with your product design. At the same time, we have a professional R&D team. If you need special features and requirements, you can also communicate your ideas with us.
(3) Q: What are the most advantages in a highly competitive market?
A: Our strengths are professional design, good quality control, guaranteed delivery time, effective and good communication and reasonable prices.
Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor, Laser Distance Meter Sensor, Long Rangefinder Module, TOF High Frequency LiDAR Sensor.
