1800m Rangefinder Sensor usually refers a laser ranging module or sensor component with a maximum measuring range of up to 1800 meters. These products mostly adopt 905nm near- laser and TOF (Time of Flight) pulse ranging principles, serving as core components in drone gimbals, security monitoring, outdoor sports equipment (such as golf rangefinders, hunting rangefinders), and industrial inspection equipment.

If you need two samples for testing, please contact us: jane.l@jrt-measure.com. or WeChat: 0086-17708191805.

Typical Products and Core Parameters
The following are several representative 1800m rangefinder sensors covering different power consumption, size, and interface requirements:
1. The JRT PTYS-18X series is a relatively common long-range module on the market compact in size, measuring about 26×25×13.5mm, and weighing only 12g. It uses a 90nm laser, and under good visibility and large target conditions, the measuring range can exceed 2000m, while for human-shaped targets it is about 00m. Accuracy varies with distance: about ±0.5m within 80m, about ±1m within 1000m and ±(0.2 0.0015×D) m for longer distances. The ranging frequency supports single shot, 1Hz, Hz, and 5Hz, with UART serial communication. -2-8-10

If you have specific integration requirements (such as interface types or size constraints), please let us know: jane.l@jrt-measure.com. or WeChat: 0086-17708191805., and I can help you select a more suitable model.

2. The JRT PTGL2-18X focuses on high frequency dynamic ranging, with a refresh rate reaching 20Hz, suitable for drone gimbals tracking moving targets. Its accuracy within 100m can reach0.3m, with a blind zone as low as 0.3m, supporting stable measurement under light haze conditions.

3. The JRT LRF-150M series is an industrial-grade product, with a measuring range of up to 150m for cooperative targets and an accuracy of ±3mm. Its features include a high protection rating (IP65) and wide voltage supply (6-36VDC), making it suitable for integration into fixed such as port monitoring and traffic surveillance.

Order Now!

Key Selection Points
When choosing an 1800m rangefinder sensor, there are several parameters to pay special to:
Measuring range is strongly correlated with target attributes. The nominal 1800m is usually data under "large target, high reflectivity, and good" conditions. For diffuse reflection targets such as humans and animals, the actual measuring range will drop significantly, possibly to only 700m or even shorter.
Accuracy is usually segmented. Most modules have higher accuracy at short distances (e.g., within 100m), and the accuracy at long distances will as the distance increases. -1-8
Interface and integration difficulty. Most modules provide UART TTL serial output, with voltages mostly at 3.3V or5V, making it easy to directly connect to the main control MCU. Some industrial models will provide RS232 or RS422.
If you tell me the specific application (such as drones, handheld devices, industrial monitoring), I can help you further determine which type of module is more suitable.

For more projects suggestions, welcome contact us: jane.l@jrt-measure.com. or WeChat: 0086-17708191805.

For more, welcome contact us: jane.l@jrt-measure.com. or WeChat: 0086-17708191805.

Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor,1535nm Rangefinder Module, TOF High Frequency LiDAR Sensor.
