20km Ranging Sensor
Transducer Model: ETYS-20KX-1(k261019n-8)
Working Wavelength: 1535 nm ± 5 nm
Measurement capability: 20,000 m for car or equivalent large targets
Measurement Accuracy: ± 3 m
Baud Rate: 38,400 bps (Default)
Weight: ≤ 790 g
Dimensions: ≤ 134 mm × 99 mm × 77 mm
Power Supply Voltage: 22 V – 34 V
Communication: RS422
1800m Rangefinder Sensor
20km Ranging Sensor
A 20km ranging sensor is typically a high-performance laser rangefinder module, primarily used in security, and industrial inspection fields. The laser range finding sensor's core feature is the use of 1535nm (1550nm or 1565nm) eye-safe wavelength lasers, achieving long-distance measurement of up to 20 kilometers through time-of-flight (ToF) principles.
If you need order samples for testing, please contact us: jane.l@jrt-measure.com. or WeChat: 0086-17708191805.
Below is one of representative 20km ranging sensor products and key specifications:
JRT ETYS-20KX (LONG RANGE)
Wavelength and Range: 1535nm, maximum range up to 20km (large target), minimum range 0.1km, vehicle targets approximately 15km, human targets approximately 6km, UAV targets approximately 4.5km.
Accuracy and Resolution: Measurement accuracy ≤≤±3m, resolution 50m.
Physical and Interface: Dimensions 134mm×99mm×77mm, powered by 22V～34V wide voltage input, supports RS422 interfaces etc.
Features: Adopts high-grade 1535nm er-glass laser technology design, compact and lightweight, low power consumption (<2.5W), Class 1 eye-safe. , high reliability, ideal for pod, vehicle-mounted platforms, or photoelectric tracking systems.
If you have any other requirements (such as interface types), please let us know: jane.l@jrt-measure.com. or WeChat: 0086-17708191805., and I can help you select a more suitable model.
Technical Parameters:
1 Operating Wavelength: 1535 nm ± 5 nm
3 Transmit Aperture: Φ15 mm
4 Receive Aperture: Φ66 mm
5 Ranging Capability: ≥ 25,000 m (Typical reference value for large targets)
≥ 20,000 m (2.3 m × 4.6 m standard target board or equivalent target)
6 Ranging Blind Zone: ≤ 100 m
7 Ranging Accuracy: ≤ ± 3 m
8 Measurement Success Rate: ≥ 98%
9 False Alarm Rate: ≤ 2%
10 Distance Resolution: ≤ 50 m
11 Ranging Frequency: Single-shot; 1–5 Hz
12 Baud Rate: 38,400 bps (Default) / 9,600 bps / 57,600 bps / 115,200 bps
13 Weight: ≤ 790 g
14 Dimensions: ≤ 134 mm × 99 mm × 77 mm
15 Electrical Interface: Connector Plug: J30J-9TJL
Connector Socket: J30J-9ZKP
16 Power Supply Voltage: 22 V – 34 V
17 Standby Power Consumption: ≤ 2.5 W
18 Average Power Consumption: ≤ 3.8 W @ 1 Hz; 18 W @ 5 Hz
19 Operating Temperature: -40°C – +60°C (Defense Grade)
20 Storage Temperature: -45°C – +65°C (Defense Grade)
For more projects suggestions, welcome contact us: jane.l@jrt-measure.com. or WeChat: 0086-17708191805.
For more, welcome contact us: jane.l@jrt-measure.com. or WeChat: 0086-17708191805.
Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor,1535nm Rangefinder Module, TOF High Frequency LiDAR Sensor.
