Miniaturized Laser Sensors Rangefinder Laser Distance Meter 10m
Brand Name: JRT
Measuring Range: 0.03-10m
Frequency: 3Hz
Accuracy：+/-1mm
Support RS232, RS485, USB, Bluetooth and other interfaces
10m high accuracy laser distance sensor short range
Product Description:
Laser ranging is the use of laser as the main working substance to work. At present, China's domestic laser ranging market is favored by more and more enterprises, and its use in various industries has been recognized by consumers. Industrial laser distance sensors measure from 0.03 to 10 meters. And the measurement is fast, the measurement time is 0.125~4 seconds.
application area
Agricultural product transportation monitoring
Feed measurement management
Feature
Specifications of Laser Distance Sensor:
|
Certification |
FDA/ISO9001 |
|
Place of Origin |
China |
|
Accuracy |
±1 mm |
|
Measuring Unit |
mm |
|
Measuring Range |
0.03-10m |
|
Measuring Time |
0.125~4 seconds |
|
Laser Class |
Class II |
|
Laser Type |
620-690nm, <1mW |
|
Size |
45*25*12mm (±1 mm) |
|
Weight |
About 10g |
|
Voltage |
DC2.0~3.3V |
|
Electrical Level |
TTL/CMOS |
|
Frequency |
3HZ / 8hz |
|
Operating Temperature |
0-40 ℃ (32-104 ℉ ) |
|
Storage Temperature |
-25~60 ℃ (-13~140 ℉) |
|
Packaging |
Neutral packing |
Key parameters:
1. Reliable, fast, precise
Accuracy: +-1 mm
Measuring time: 0.125s-4s
2.Small, long range
Size:41x17x7mm
Measuring range up to 10 m
U81 U85 laser working principle
The optical distance sensors achieve 10m short-range presence detection using a visible, focused laser beam spot. According to the latest version, customers can test the laser range components simply via using all available distance functions commond of the hexadecimal system. High resolution up to 1mm, the arduino distance measurement laser usually used to some samrt monitoring project.
Product picture:
