Flange Gauge Pressure Transmitter

As a shock-proof pressure gauge, the flange diaphragm pressure gauge, using indirect measuring structure, suitable for measuring the viscosity of large, easy crystallization, corrosive, high temperature of liquid, gas or granular solid medium pressure. Flange pressure transmitter isolators and diaphragms are available in a variety of materials to adapt to a variety of corrosive media. The flange gauge is mainly used for pressure measurement in petroleum, chemical, pharmaceutical, food, textile, agriculture and animal husbandry industries. If you are interested in this capsule pressure gauge manometer, please feel free to contact us.

Have a wonderfull day

Product model: PT44001-1(k240319-2)

Tag Number: PT-44001

Ambient Temp.: Relative Humality -42.8～43.1℃ 44～85%

* PRESSURE TRANSMITTER

Type: Pressure transmitter, diaphragm type pressure transmitter

Measuring Principle: Monocrystalline silicon resonant, capacitive

Calibrated Range MPa: user-provided

Intergral Meter: LCD digital watch head, without display head

Supply Power: 24VDC

Output Signal: Two-wire system/4~20mADC+HART

Correctness: Repeatability ±0.5%, ±0.2%, ±0.1%, ±0.075% ≤±0.05%

Body Material: 304SS

Element Material: 316SS

Housing Material: Cast aluminum coated polyurethane

Process Connection: 1/2"NPT(F), M20X1.5

Conduit Connection Size: 1/2"NPT(F), M20X1.5

Explosion Proof: No require, Ex dII BT4, Ex dII CT4, Ex iaII CT4

IP Code: IP65

Mounting Style: Direct screw mounting, flange mounting

Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor, Rangefinder Module, TOF High Frequency LiDAR Sensor, Instrument And Measurement Tools.

For more info, please feel free to contact us
