4 20ma Pressure Transducer
Pressure Transducer Model: JRTPS-1(k240318-1)
1. Zero full scale can be adjusted
2. Output: 0~5V/0~10V, 4-20mA
3. Accuracy: better than 0.5%FS
4. Good stability and repeatability
5. Can replace similar products
4 20ma Pressure Transducer
This pressure transducer sensor has the characteristics of high accuracy, 4-20mA temperature and pressure integrated transmitter, 0-10V wide pressure design, diaphragm high temperature resistance, wide range and high stability. It has been widely used in industrial automation, automotive industry, medical equipment, aerospace and other fields. If your project need order some sample to test, welcome to contact us.
Product Specifications
Pressure range: 0….3.5 MPa to 0….150MPa
Output: 0~5V; 0~10V; 4-20mA;
Input voltage: 24(12~36V)DC
Accuracy: ±0.25FSO ; ±0.5%FS
(including linearity, Repeatability & Hysteresis )
Repeatability: ±0.2% FSO
Construction: Wheatstone bridge
Bridge resistance: Input: 345 Ohms Minimum; Output: 350 Ohms±10%
Overload pressure: 1.5×FSO
Internal shunt calibration: 80%±1%
Insulation Resistance: 200Megohms @100Vdc
Standard wetted Parts Diaphragm coated 15-5PH SST
Mounting Torque 500inch/lbs, maximum
Max. Diaphragm Temp: 0~550 ℃
Electronic operating temperature: -25~85 ℃
Electric connector: 5PIN;6PIN
Rigid Length: 6", 9" (Customer design)
Flexible Length: 18" , 30" (Customer design)
Thermocouple type: J, K, E, PT100 Optional (only for temperature and pressure type )
Process connection: 1/2″-20UNF, M14×1.5, M18×1.5(Customer design)
Picture Show
Product Structure
Product Dimensions
Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor, Rangefinder Module, TOF High Frequency LiDAR Sensor, Instrument And Measurement Tools.
For more info, please feel free to contact us
