Laser Sensor For Distance Measurement Non Contact Distance Sensor
Product Category：Laser distance module
Product Number：M88-60m(k200103)
Measuring range：0.03-60m
Accuracy：+/-1mm
Weight: about 9g
Laser Expert JRT says: This JRT length measurement sensor, default serial communication. Also, you can choose USB, RS-232, RS-485, Bluetooth wireless distance transmission data; Laser ranging can reply the measurement signals in real time. The range module supports secondary development. Welcome to contact us for more: info@jrt-measure.com.
Laser Sensor For Distance Measurement Non Contact Distance Sensor
Laser Expert JRT says: This length measurement sensor, default serial communication. Also, you can choose USB, RS-232, RS-485, Bluetooth wireless distance transmission data; Laser ranging can reply the measurement signals in real time. The range module supports secondary development. Welcome to contact us for more: info@jrt-measure.com.
Description：
Laser ranging sensors are mainly used for non-contact precise ranging, which can be integrated into obstacle avoidance positioning of sweeping robots, AGVs, and drones.
60m Laser Distance Module：
Brand Name | JRT |
Product Name | Laser Distance Meter Sensors |
Model Number | M88-60m(k200103) |
Certificate | FDA/ISO9001 |
Place of Origin | Chengdu |
Accuracy | ±1 mm (0.04 inch) |
Measuring Unit | mm |
Measuring Range (without Reflection) | 0.03-60m |
Measuring Time | 0.125~4 seconds |
Laser Class | Class II |
Laser Type | 635nm,<1mW |
Size | 49*25*13mm (±1 mm) |
Weight | About 9g |
Voltage | DC2.0~3.3V |
Electrical Level | TTL/CMOS |
Frequency | 3Hz |
Operating Temperature | 0-40 ℃ |
Storage Temperature | -25~60 ℃ |
Packaging | Neutral packing |
Note:
1. Under poor measurement conditions (such as excessive ambient light, too large or too small diffuse reflection coefficient of the measured point), the measurement accuracy will have a large error: ± 1 mm + 40PPM.
2. In the case of strong sunlight or poor target reflection, please use a reflector.
3. If the working range needs -10 C ° ～ 50 C °, it needs to be customized.
Product picture：
Features:
1. Non-contact precise ranging.
2. 1mm measurement accuracy.
3. Industrial applications ranging sensors.
4. Serial TTL output.
Pin Informatica：
FAQ：
(1) Q: Does your product have a shelf life?
Answer: Our product is guaranteed for 1 year. If you have any quality problems within 1 year, you can contact us.
(2) Q: What is the best price?
A: We will provide you the best price based on your quantity, so please let us know your quantity when you make an inquiry.
(3) Q: Do you accept ODM and OEM?
A: We accept ODM and OEM orders. We produce factories and can provide related services.
(4) Q: Do you provide free samples?
A: We do not provide free samples, but if we have reached a cooperation later, we can apply to return the sample fee to you.
Terms of Service:
We will respond to your questions within 24 hours;
We provide a one-year warranty and lifetime technical support;
We will ship in time and inform you in time.
Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor, Laser Distance Meter Sensor, Long Rangefinder Module, TOF High Frequency LiDAR Sensor.
For more info, please feel free to contact us
