Golf Laser Range Finders
Range Finders Model: PTF-LRF40X(k240905n-7)
Range: 3000/4000 yards
Accuracy: +/- 1 yard@1000yards
Magnification: 8X,10X,12X options
Dimension: 173*131*65mm/ 167*131*65mm
Weight: 982g(Alu)/912g(Al-mg alloy)
Applications: Golf, hunting, night vision etc. in outdoors
Golf Laser Range Finders
The PTF-LRF40X laser range finder is a accurate & long-range laser measure tool. With 8X magnification, the golf laser rangefinder makes the distance display on the screen clear and visible. Also, the detailed manuals explained for the usage of the assembly units to makes it easily. If you have any other requirements want to know, please contact us.
Technical Parameters
Magnification: 8X 10X 12X
Objective Lens Diameter: 42 mm
Range Reflective: 5-5,000 yards
Range Tree: 3000 yards(Basic Model) / 4000 yards(Pro Version )
Range Deer: 1200 yards /1600 yards
Accuracy: +/- 1 yard@1000yards
Linear Field of View: 300 ft/1000 yds 290ft/1000yds
Angular Field of View: 5.7 degrees 5degrees
Eye Relief: 17mm 15mm
Exit Pupil: 5.3 mm 4.2mm
Dimension: 173*131*65mm/ 167*131*65mm
Weight: 982g(Alu) / 912g (Al-mg alloy)
DISPLAY TYPE: OLED RED
Prism Glass: Bak4
Close Focus: 16feet
Multi-Coated: Yes
Diopter Adjustment: +/-5
Waterproof: IPX6
Phase Film: Pro Version: Yes
Material: Alu / Al-mg alloy
Ballistic: Optional
rangefinder accessories
binocular telescope key features
Range ability: 5-5000 meters
Magnification: 8X 10X 12X
Lens Diameter: 42 mm
How to use the range finders?
Binocular optics setting/adjustment
Adjust the interpupillary distance
The interpupillary distance is the distance between the centers of the left and right eye pupils. Match the interpupillary distance of your eyes to that of the binocular so that you see a single image that is free of shading.
Rotate the binocular barrels inward or outward to line your eyes up with ocular lenses.
Buttons detailed descriptions
1. Eyepiece lens
2. Eyecup
3. Diopter adjustment ring
4. Internal display diopter adjustment ring
5. Battery compartment cap
6. Power on button
7. Mode button
8. Center focus
9. Tripod adapter hole
10. Objective lens
11. Eyepiece lens cover
12. Strap attachment
13. Objective lens cover
Chengdu JRT Main Ranging Sensors: Industrial Laser Distance Sensor, Rangefinder Module, TOF High Frequency LiDAR Sensor, Instrument And Measurement Tools.
For more info, please feel free to contact us.
