Laser Ranging Module Measuring Moving Objects TOF
Product Number：IT03S
Measuring Distance：0.1-15m
Accuracy：5cm
Size：50*26*13mm
What is the difference between TOF laser ranging module and ordinary laser ranging sensor?
JRT's conventional laser ranging module is generally used to measure static targets and is not suitable for measuring fast moving targets. In vehicle traffic, human traffic, industrial robot obstacle avoidance, automobile collision avoidance, etc., higher-frequency ranging products are needed. At this time, the TOF ranging sensor can exert its advantages. The TOF laser ranging module can reach 100HZ It can measure 100 times in one second, and it can also measure the data for objects with speed.
Our low-frequency laser ranging module has millimeter-level accuracy, and tof high-frequency distance sensors have centimeter-level accuracy. Please choose the right product according to your needs.
Product parameters：
| Module | IT03S |
| Range | 0.1-15m@70% reflectance |
Frequency | 100Hz |
Accuracy | +/- 2cm @ 70% reflectance |
Absolute Accuracy | +/-5cm@ 0.1~2.5m； +/-2% @2.5-15m |
Blind Area | 10cm |
Resolution | 1cm |
Light | 650nm red laser, Class II，<1mw @ 100Hz (Customizable 780nm version) |
Resistance to Light | 10000 LUX |
Voltage | DC +3.3V |
Current | ~50mA @ 100Hz |
Power | 166mw@100Hz |
Volume | 50*26*13mm |
Weight | ~10g |
Serial level | TTL 3.3V |
Features:
1. Outdoor measurement distance up to 15m, also has good adaptability under strong outdoor light;
2. The black target can also reach a distance of 12 ~ 15m;
3. High and low temperature resistance -0 ~ + 50 ℃;
4. Compact size, width 26mm, length 50mm, height 13mm;
5. UART TTL level output distance value of the measured object, easy to use;
Product Picture：
